Electrical Data | |
|---|---|
| Supply Voltage | 18...32 V DC |
| Power consumption of device max. | 0,1 A |
| Power consumption of system max. | 1,8 A |
| Max. Switching Current Switching Outputs | 0,6 A |
| max. total current of the digital I/O ports | 9 A |
| Switching Output Voltage Drop | <{} 2,5 V |
| Temperature Range | -25...60 °C |
| Sensor Supply Voltage (Pin 1) | 200 mA |
| Inputs according to DIN EN 61131-2:2003 | Type 2 |
| Digital I/O ports short circuit protected | yes |
| Digital I/O ports overload protected | yes |
| Digital I/O ports reverse polarity protected | yes |
| Standard I/O-Pins | 16 |
| Baud Rate | 10/100 Mbit/s |
| Transmission Mode | Full/Half Duplex |
| Switch Mode | Store &{} Forward |
| VLAN Prioritization | yes |
| Auto-Crossover | yes |
| Auto-Negotiating | yes |
| Auto-Polarity | yes |
| Interface | PROFINET |
| Protection Class | III |
Mechanical Data | |
| Material | Aluminum |
| Weight | 1100 g |
| Degree of Protection | IP67 |
| Type of Connection Power | 2 ? 7/8"{}, 5-pin |
| Type of Connection Industrial Ethernet Ports | 2 ? M12{} 4-pin |
| Type of connection digital I/O ports | 8 ? M12{} 4-pin |
Safety-relevant Data | |
| MTTFd (EN ISO 13849-1) | 255,49 a |
General Data | |
| Web server | yes |
Output | |
| PROFINET IO, CC-B | yes |
Connection Table | |
 | |
Complementary Products | |
| Locking Screw for 7/8"{} Z0028 | |
| Locking Screw for M12 Z0027 | |
