Electrical Data | |
|---|---|
| Supply Voltage | 18...30 V DC |
| max. total current of the digital I/O ports | 1,6 A |
| Temperature Range | 0...55 °C |
| Short Circuit Protection | yes |
| Overload Protection | yes |
| Number of IO-link ports | 4 |
| Number of digital I/O ports | 4 |
| Interface | PROFIBUS DP |
| Communication Mode IO-Link | SIO, COM2, COM3 |
| IO-Link Version | 1.0 |
| IO-link port | Class A |
| Baud Rate | >{} 12 MBd |
| Feldbus Diagnosis | LED |
| IO-Link Parameter | >{} 12 |
| Protection Class | III |
Mechanical Data | |
| Material | Zinc diecasting |
| Weight | 822 g |
| Degree of Protection | IP67 |
| Connection Mode Supply Voltage | 2 ? 7/8"{}, 5-pin |
| Connection Bus Side | M12 ? 1{} 4-pin |
| Type of connection digital I/O ports | M12 ? 1{} 4-pin |
Output | |
| IO-Link | yes |
Complementary Products | |
| Locking Screw for 7/8"{} Z0028 | |
| Locking Screw for M12 Z0027 | |
| TCI Tool DNNF011 | |
