ASi Analog Input Module, IP67, M12, 2AI (4…20mA)



ASi Analog Input Module in IP67, with 4 x M12 sockets, 2 analog inputs (4…20 mA), signal at pin2/pin4, input voltage/sensor supply out of ASi, periphery connection via 2 x M12 sockets, 5 poles, ASi connection via profile cable and piercing technology, 1 AB slave The substructure module is not included in the scope of delivery.

ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
Type			IP67, 4 x M12
ASi-5/ASi-3			ASi-3 compatible
Housing			4 x M12
Protection rating			IP67
Primary application			-
Flat design, installation in cable duct possible			-
Inputs digital			-
Inputs Safety, SIL 3, Cat. 4			-
Outputs digital			-
Inputs analog			2 x 4 … 20 mA
Outputs analog			-
Safety signal inputs			-
M8/M12 wiring			Signal at pin2/pin4
Input voltage (sensor supply)			out of ASi
Output voltage (actuator supply)			-
Connection			2 x M12 sockets, 5 poles
Round cable			-
ASi connection			ASi profile cable
ASi address			1 AB address
Special function			-
