TF3520 | TC3 Analytics Storage Provider
The TwinCAT 3 Analytics Storage Provider is an IoT client and forms the interface to one or more storage facilities or databases for raw and analysis data from various sources. The data is stored as a binary blob in the storage medium. Microsoft Azure Blob supports a public cloud, while Microsoft SQL supports an on-premises database. In this way, both applications can be covered. The Analytics Storage Provider automatically structures and stores the data. The storage interface can be configured via TwinCAT Engineering in Microsoft Visual Studio®. Data is selected centrally for reading and writing via the TwinCAT Target Browser. The user selects the data via the user-defined variable name in the machine application and the corresponding time period; no complex SQL commands are required. Historical data can be sourced via the TF3500 TC3 Analytics Logger, the TF6720 TC3 IoT Data Agent or the EK9160 IoT Bus Coupler. The corresponding dИли отправьте нам запрос на3 Analytics Service Tool and the TE3500 TC3 Analytics Workbench.
| Technical data | TF3520 |
|---|---|
| Required | TC1000 |
| Target system | Windows 7/8/10 |
| Ordering information | |
|---|---|
| TF3520-0v40 | TC3 Analytics Storage Provider, platform 40 (Performance) |
| TF3520-0v50 | TC3 Analytics Storage Provider, platform 50 (Performance Plus) |
| TF3520-0v60 | TC3 Analytics Storage Provider, platform 60 (Mid Performance) |
| TF3520-0v70 | TC3 Analytics Storage Provider, platform 70 (High Performance) |
| TF3520-0v80 | TC3 Analytics Storage Provider, platform 80 (Very High Performance) |
| TF3520-0v81 | TC3 Analytics Storage Provider, platform 81 (Many-core 5…8 Cores) |
| TF3520-0v82 | TC3 Analytics Storage Provider, platform 82 (Many-core 9…16 Cores) |
| TF3520-0v83 | TC3 Analytics Storage Provider, platform 83 (Many-core 17…32 Cores) |
| TF3520-0v84 | TC3 Analytics Storage Provider, platform 84 (Many-core 33…64 Cores) |
| TF3520-0v90 | TC3 Analytics Storage Provider, platform 90 (Other) |
| TF3520-0v91 | TC3 Analytics Storage Provider, platform 91 (Other 5…8 Cores) |
| TF3520-0v92 | TC3 Analytics Storage Provider, platform 92 (Other 9…16 Cores) |
| TF3520-0v93 | TC3 Analytics Storage Provider, platform 93 (Other 17…32 Cores) |
| TF3520-0v94 | TC3 Analytics Storage Provider, platform 94 (Other 33…64 Cores) |
| Product announcement | estimated market release 2nd quarter 2019 |
