EL9221 | Overcurrent protection terminal, 24 V DC, 1-channel, max. 10 A, adjustable
Описание
Информация для заказа
Technical data | EL9221-5000 |
---|---|
Technology | overcurrent protection terminal 24 V DC, 1-channel |
Nominal voltage | 24 V DC |
Number of outputs | 1 |
Number of inputs | 1 |
Input current | max. 10 A |
Rated current | adjustable from 1…10 A in 1 A steps |
Hold after output switch-off | ≥10 s |
Advance warning output load | 90 % |
Over voltage power-off | ≥ 32 V DC |
Advance warning low-voltage | – |
Reverse polarity switch-off | – |
Current consumption E-bus | typ. 80 mA |
Electrical isolation | 500 V (E-bus/signal voltage) |
Weight | approx. 55 g |
Operating/storage temperature | 0…+55 °C/-25…+85 °C |
Protect. class/installation pos. | IP 20/see documentation |
Approvals/Markings | CE |
Ordering information | All variants | Standard functionalities |
---|---|
EL9221-4030 | overcurrent protection terminal 24 V DC, 1-channel, 3 A |
EL9221-5000 | overcurrent protection terminal 24 V DC, 1-channel, max. 10 A, adjustable |
EL9221-6000 | overcurrent protection terminal 24 V DC, 1-channel, max. 4 A, adjustable |
EL9221-5090 | overcurrent protection terminal 24 V DC, 1-channel, 10 A |
EL9221-6040 | overcurrent protection terminal 24 V DC, 1-channel, 4 A |
EL9221-9060 | overcurrent protection terminal 24 V DC, 1-channel, 6 A |
EL9221-9080 | overcurrent protection terminal 24 V DC, 1-channel, 8 A |
