Steering column switch 151LSS…
Описание
Информация для заказа
Attribute | 151LSS... |
---|---|
Electrical data | |
Max. switching voltage | 12 V DC |
Contact form | mechanical |
Turn signal - max. switching voltage | 12 V DC |
Turn signal - max. switching current | 10.5 A |
Turn signal - max. switching power | 6x21 W |
Horn - max. switching voltage | 12 V DC |
Horn - max. switching current | 5.5 A |
Horn - max. switching power | 66 W |
Headlamp flasher – max. switching voltage | 12 V DC |
Headlamp flasher – max. switching current | 10.8 A |
Headlamp flasher – max. switching power | 2x65 W |
Deflection - turn signal | 13 ° |
Deflection - headlamp flasher | 4 ° |
Deflection - high beam | 10 ° |
Deflection – LCP indicator | 8 ° |
Contact form - turn signal | mechanisch |
High beam – max. switching voltage | 12 V DC |
High beam – max. switching current | 10.8 A |
High beam – max. switching power | 2x65 W |
Low beam – max. switching voltage | 12 V DC |
Low beam – max. switching current | 9.1 A |
Low beam – max. switching power | 2x55 W |
Continuous wiper operation – max. switching voltage | 12 V DC |
Continuous wiper operation – max. switching current | 8 A |
Continuous wiper operation – max. switching power | ca. 96 W |
Interval wiper operation – max. switching voltage | 12 V DC |
Interval wiper operation – max. switching current | 8 A |
Interval wiper operation – max. switching power | ca. 96 W |
Stroke washer – max. switching voltage | 12 V DC |
Stroke washer – max. switching current | 5 A |
Stroke washer – max. switching power | ca. 60 W |
Mechanical data | |
Steering column diameter | 45 mm |
Material information | |
Housing material | Druckguss |
Shaft material | Stahl |
Gaiter material | EPDM |
Environmental conditions | |
Protection class, electronic | IP6K7 DIN40050 Part 9 |
Operating temperature min. | -30 °C |
Max. operating temperature | 70 °C |
Min. storage temperature | -40 °C |
Max. storage temperature | 80 °C |
