EloProg input/output module 485EPE08A02
Описание
Информация для заказа
| Attribute | 485EPE08A02 |
|---|---|
| Connection to base module | propriertary 5-way bus (T-connector) |
| Torque for connection terminals | 0.6 N m |
Electrical data | |
| Max. switching voltage at safety output | 24 V DC |
| Max. switching voltage at control output | 24 V DC |
| Max. switching current at safety output | 0.4 A |
| Max. switching current at control output | 0.1 A |
| Contact form | ? |
| Number of configurable electronic safety outputs | 2 |
| Number of electronic control outputs | 2 |
| Number of test outputs (clocked) | 8 |
| Number of safety inputs | 8 |
| Stop category 0 (STO) nach IEC 61800-5-2 | Depending on the configuration |
| Stop category 1 (SS1) nach IEC 61800-5-2 | Depending on the configuration |
| EDM/start input | Depending on the configuration |
| Start function | Depending on the configuration |
| Feedback circuit | Depending on the configuration |
| Start-up test present | Depending on the configuration |
| Operating voltage min. | 19.2 V DC |
| Operating voltage max. | 28.8 V DC |
| Power consumption | 3 W |
| Wire-break detection | Depending on the configuration |
| Short-circuit detection | Depending on the configuration |
| Cross-short detection | Depending on the configuration |
| LED display | four-coloured |
| Operating time | Depending on the configuration ms |
| Response time | depending on the configuration ms |
Safety-related characteristics | |
| PL acc. to EN ISO 13849-1 | e |
| SIL acc. to IEC 61508 | 3 |
| SIL CL acc. to IEC 62061 | 3 |
| PFHD according to IEC 61508 | 5,72 x 10-9 1/h |
| Operating life | 20 Tm |
| Category acc. to EN ISO 13849-1 | 4 |
Mechanical data | |
| Dimensions | 108 x 22,5 x 114,5 mm (H/B/T) |
Material information | |
| Housing material | PA |
| Housing colour | Gehaeuse schwarz Frontplatte gelb |
Environmental conditions | |
| Protection class, housing | IP20 DIN EN 60529 |
| Operating temperature min. | -10 °C |
| Max. operating temperature | 55 °C |
| Min. storage temperature | -20 °C |
| Max. storage temperature | 85 °C |
| Relat | |
- Цена: Цену уточняйте
