EloProg base module 485EPB
Описание
Характеристики
Информация для заказа
Attribute | 485EPB |
---|---|
Housing colour | Gehause schwarz Frontplatte gelb |
Electrical data | |
Max. switching voltage at safety output | 24 V DC |
Max. switching voltage at control output | 24 V DC |
Max. switching current at safety output | 0.4 A |
Max. switching current at control output | 0.1 A |
Number of configurable electronic safety outputs | 2 |
Number of electronic control outputs | 2 |
Number of test outputs (clocked) | 4 |
Number of safety inputs | 8 |
Stop category 0 (STO) nach IEC 61800-5-2 | Depending on the configuration |
Stop category 1 (SS1) nach IEC 61800-5-2 | Depending on the configuration |
EDM/start input | Depending on the configuration |
Start function | Depending on the configuration |
Feedback circuit | Depending on the configuration |
Start-up test present | Depending on the configuration |
LED display | five-coloured |
Overvoltage category | II |
Pollution degree | 2 |
Operating voltage min. | 19.2 V DC |
Operating voltage max. | 28.8 V DC |
Short-circuit detection | Depending on the configuration |
Cross-short detection | Depending on the configuration |
Wire-break detection | Depending on the configuration |
Power consumption | 3 W |
Operating time | Depending on the configuration ms |
Response time | 10,6 - 12,6 ms |
Safety-related characteristics | |
PL acc. to EN ISO 13849-1 | e |
SIL acc. to IEC 61508 | 3 |
SIL CL acc. to IEC 62061 | 3 |
PFHD according to IEC 61508 | 6,06 x 10-9 1/h |
DC | 99% <= dc="" (high)="" %=""> |
Category acc. to EN ISO 13849-1 | 4 |
Type | 4 EN 61496-1 |
mttfd | 30 bis 100 a Tm |
Mechanical data | |
Dimensions | 108 x 22,5 x 114,5 mm (H/B/T) |
Material information | |
Housing material | PA |
Environmental conditions | |
Protection class, housing | IP20 DIN EN 60529 |
Operating temperature min. | -10 °C |
Max. operating temperature | 55 °C |
Min. storage temperature | -20 °C |
Max. storage temperature | 85 °C |
Основные | |
---|---|
Производитель | Cross |
- Цена: Цену уточняйте
