Safety sensor 122MSV
Описание
Информация для заказа
Attribute | 122MSV10G1G |
---|---|
Electrical data | |
Min. switching voltage | 19.2 V DC |
Max. switching voltage | 28.8 V DC |
Max. switching current | 0.1 A |
Max. switching power | 3 W |
Switching frequency | 5 Hz |
Assured switching distance (Sao) | 9.5 mm |
Assured switch-off distance (Sar) | 25 mm |
Minimum switching distance (S0 min) | 0.5 mm |
LED display | No |
Actuation | front |
Switching principle | magnetic |
Series resistor | 22 Ohm |
Technology | Reed |
Contact form | NO/NC |
Pollution degree | 3 |
Protection class | III |
Safety-related characteristics | |
Coding acc. to EN ISO 14119 | Low |
B10d acc. to EN ISO 13849-1 | 20000000 |
Type acc. to EN ISO 14119 | 4 |
Mission time in years | 20 a |
Structure acc. to EN ISO 13849-1 | Two-channel |
Properties | |
Housing colour | silber |
Mechanical data | |
Housing design | cylindrical |
Dimensions | M12 x 55,5 mm |
Detent present | no |
cannot be mounted flush | yes |
Material information | |
Housing material | Edelstahl |
Nut material | Edelstahl |
Environmental conditions | |
Protection class | IP68 DIN EN 60529 |
Protection class, connector | IP68 DIN EN 60529 |
Operating temperature min. | -25 °C |
Max. operating temperature | 80 °C |
Shock resistance (Norm) | 30g / 11ms |
Vibration resistance (Norm) | 10 - 55Hz |
Min. storage temperature | -25 °C |
Max. storage temperature | 80 °C |
Installation | |
Mounting type | Fastening nut |
Thread | M12 |
Connection | |
Connector type | M12x1 - 4 polig |
Approvals | |
CE label | yes |
